Ridge Line II 27.5" Non-boost Wheels

Offering exceptional value, great performance and reliability, the Ridge Line II series are our feature packed entry level, Thru-axle and tubeless compatible MTB wheels.

With a 30mm internal and 35mm external width, the rim is well suited to most modern MTB tyres from 2.25 to 2.8”.  Tubeless compatible using a hooked bead profile also offers compatibility with traditional clincher tyres and inner tube if so desired.

Hand built with 32 no-nonsense plain gauge J-bend spokes and durable brass nipples front and rear into stainless rim eyelets, we have built these wheels to last.

At the heart of these wheels are our RL II series hubs in standard MTB widths for Thru-axle frames and forks making them a no fuss option for modern trail riders.

The rear hubs also feature high-strength Cro-Mo axles and 4-pawl Cr-Mo HG type freehubs with excellent engagement.

A Shimano Microspline type freehub option is also available in Boost spacing.

Optional aftermarket end caps enable the hubs to fit with most frame or fork configurations including Quick Release.

Please see: RL II Front Hub or RL II Rear Hub for more hub information.

Included Fittings

• Front Standard 100 x 15mm thru
• Rear Standard 142 x 12mm

Specifications

• Rims Ridge Line double wall alloy with stainless eyelets
• Hubs RL II with sealed bearings
• Spokes 32x Black plain gauge, J-bend spokes
• Nipples Black ED coated brass nipples
• Rim Depth 17.7mm
• Internal Rim Width 30mm
• External Rim Width 35mm
• Front Hub Spacing 100 (MTB) (QR or 12mm aftermarket options)
• Rear Hub Spacing 142 (MTB) (QR 135/141 aftermarket option)
• Drillings 32H front, 32H rear
• Freehub Type Shimano HG Cr-Mo or Micro-Spline options
• Disc Mount 6 Bolt
• Recommended Tyre size 2.25 - 2.8”
• Tubeless Tubeless ready
• Colour Anodised black hub and rim with subtle white decal
